適用范圍：

適用于各種布料、無紡布、泡棉、皮革、紙張、反光材料、醋酸布、補強帶、導電布等材料圓包裝及各種織物工切捆條前的驗布及重復打卷，能卷制成直紋或45度斜紋卷材。配有半圓形放料桶，圓卷或折疊式織物均可使用。

技術參數：

門幅：1.7米（另有2.05米、2.4米、2.8米、3.2米可選）

卷布**大直徑：300毫米,也可定制400毫米

**卷布速度：80米/分鐘

卷布電機功率：1.5千瓦

小刀片電機功率：0.12千瓦

電源電壓：380V/220V可選

外形尺寸:3.6米×1.5米×1.8米

配備特點：

1.采用電子紅外線自動對邊裝置，并可手動左右移位，方便操作，使布匹等材料卷取后，布邊緣整齊一致，布料的浪費達到**少。

2.配有張力控制裝置，可根據布料種類控制卷布的松緊度。

3.配有強力擴幅裝置，布料不會卷邊皺紋，對針織面料的效果更好。

4.配有驗布燈箱及照明燈架，能準確快速的檢查出布的瑕疵。

5..配有米表自動控制裝置，可**計量布米長或碼長，并自動控制。

6.卷布速度可無級調節速，并可正反轉控制，生產效率高，節省人力，單人操作方便。

7.斜紋卷布可在20度至70度之間調節。采用不銹鋼布桶**生銹，避免沾污布料。

8.集中電氣控制箱,電氣元件分布合理,每條線都做有記號，診斷維修簡單快捷，不易出故障，控制系統更為可靠.

Application:

For a variety of fabrics, woven, foam, leather, paper, reflective material, acetate cloth, reinforced belt, conductive cloth, and other packaging materials and various round cut bundles of fabric industrial fabric and repeat the test before playing volume can be ruled or 45-degree roll made of twill sheet. Put the barrel with a semi-circular, round roll or fold the fabric can be used.

Technical parameters:

Width:1.7 m (another2.05 m ,2.4 m ,2.8 m ,3.2 m optional)

Winding diameter:300 mm ,400 mm can also be customized

Cloth fastest speed:80 m / min

Winding motor

Power: 1.5 kw

Small blade motor power: 0.12 kw

Supply voltage: 380V/220V optional

Dimensions:3.6 m ×1.5 m ×1.8 m

Feature:

1.infrared auto-edge electronic devices, and manual shift around, easy to operate, and other materials to make cloth take-up, the fabric edge of the neat line, fabric waste to a minimum.

2.With a tension control device, according to the type of control volume cloth fabric tightness.

3.Expander device with a powerful, curling fabric will not wrinkle, the knitted fabric better.

4.With a light box and cloth inspection lighting truss, can be quickly and accurately detect defects in fabric.

5.Meters with automatic control device can accurat

ely measure Bumi length or code lengt**utomatic control.

6.Winding speed can be adjusted speed, and reversing control, production efficiency and save manpower, single easy operation.

7.Twill cloth volume in between 20 degrees to 70 degrees adjustment. Stainless steel cloth bucket, never rust, to avoid contamination of fabric.

8.Focus on the electrical control box, a reasonable distribution of electrical components, mark each line are doing a diagnostic repair quick and easy, not easy to fail, the control system more reliable
